PC-B: Sawing Machine
MULTI SHEET SLICER
- This machine uses vertical shaft of circular saw blade. Multi-blade saws are parallel sawing. After sawing, enter the guiding-groove to make wood chips more precise.
- 8 pcs of upper feeding rollers and 2 pcs of lower feeding rollers run synchronously and combine with the auxiliary rollers of right saw to make feeding powerful. The auxiliary wheel of right saw can be lifted up. It is easier and more accurate to replace the saw and adjust.
- Feeding wheel is pressed work-piece by pneumatic and on synchronous drive with reduction gear. Sawing ability is powerful.
- Feeding wheels are electric. It’s easy to adjust and save time and effort.
- The working table is manufactured from alloy cast iron, vacuum heat treated, precision machined and hard chrome plated.
|Applicable sawblade diameter||2.0x1.6x30T 200mm (8")-250mm (10")|
|Max. workpiece thickness||125mm (5")|
|Width of cut||120mm for 8" saw， 170mm for 10" saw|
|Circular saw spindle dia.||40mm|
|Circular saw revolution speed||5000 RPM|
|Feeding speed||4-16m/min Variable|
|Circular saw power||20 HP x 4, 5HP x 1|
|Roller elevating power||1 HP|
|Machine size||3720 x 1560 x 1500 mm|
|Measurement||3760 x 1600 x 1700 mm|
|N.W./ G.W.||3500 kgs / 4300 kgs|
