Product Description
proimages/pro/Sander_Machine/1-01.jpg
R Type
proimages/pro/Sander_Machine/1-02.jpg
K Type
proimages/pro/Sander_Machine/1-03.jpg
RK Type
proimages/pro/Sander_Machine/1-04.jpg
RRK Type
FEATURES:
  • Computerized table-elevation.
  • Digital readout for the opening between the conveyor table and contact roller.
  • The contact roller is rubber coated and dynamically balanced.
  • Photoelectric cell controlled sanding belt tracking.
  • Automatic machine stop in the event of air failure or sanding belt breakage.
  • Quick replace sanding belt device.
MODELBKM-25RBKM-37RBKM-43RBKM-52RBKM-25KBKM-37KBKM-43KBKM-52KBKM-25RKBKM-37RKBKM-43RKBKM-52RKBKM-25RRKBKM-37RRKBKM-43RRKBKM-52RRK
Max. working width 24" 36" 42" 50" 24" 36" 42" 50" 24" 36" 42" 50" 24" 36" 42" 50"
Max. working thickness 5" 5" 5" 5" 5" 5" 5" 5" 5" 5" 5" 5" 5" 5" 5" 5"
Main motor (standard) 10HP 15HP 25HP 25HP 10HP 15HP 25HP 25HP 15、10HP 20、15HP 30、20HP 30、20HP 20、15、10HP 25、20、15HP 30、25、20HP 30、25、20HP
Main motor (optional) 20HP 25HP 40HP 40HP 20HP 25HP 40HP 40HP 20、15HP 25、20HP 40、30HP 40、30HP 25、20、15HP 30、25、20HP 40、30、25HP 40、30、25HP
Feed motor 2HP 2HP 2HP 2HP 2HP 2HP 2HP 2HP 2HP 2HP 3HP 3HP 3HP 3HP 5HP 5HP
Table hoist motor ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP ½HP
Feed speed selectable range (m/min) 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5% 6-25±5%
Sanding belt size 25"x75" 37"x75" 43"x75" 51"x75" 25"x75" 37"x75" 43"x75" 51"x75" 25"x75" 37"x75" 43"x75" 51"x75" 25"x75" 37"x75" 43"x75" 51"x75"
Working pressure (kg/cm²) 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
Net weight (kgs) 1300 1800 2100 2300 1400 1900 2200 2400 2100 2330 2850 3050 2750 3500 3750 4120
Gross weight (kgs) 1450 2000 2300 2550 1550 2100 2400 2650 2250 2650 3150 3500 3000 3800 4150 4650
Machine size (LxWxH) cm 199x139x203 190x170x203 199x193x203 199x212x203 199x139x203 188x176x203 199x193x203 199x212x203 237x139x203 230x175x203 237x193x203 237x210x203 275x139x203 243x182x225 270x200x203 270x221x207
Packing size (LxWxH) cm 202x144x223 202x175x223 202x198x223 202x217x223 202x144x223 195x183x223 202x198x223 202x217x223 240x152x223 243x182x225 245x203x223 245x216x225 280x158x223 253x215x203 285x206x225 285x227x227
