PC-B: Sawing Machine
UP AND DOWN 2-SPINDLE MULTIPLE RIP SAW
- Up and down multi-piece of saws.
- Remove the traditional chain & gear transmission, change to two-stage gear transmission. Separately drive the upper and lower feeding wheels.
- The diameter of the saw shaft is 70mm, which is convenient for assembling.
- The saw shaft is made of nickel-chromium-molybdenum of alloy steel.
- Alloy working table is embedded after double treatment of carburizing and hard chrome plating with high wear resistance .
- 10 upper and 8 lower feed rollers have powerful feeding.
- The universal joint is made of cast iron to provide maximum durability.
- Top and bottom anti-kickback fingers are for safety protection.
- Saw shaft of motor has overload protection of function.
|Max. thickness of cut||200 mm|
|Max. width of cut||240 mm|
|Saw blade diameter of upper||14" (355mm)|
|Saw blade diameter of lower||16" (403mm)|
|Saw spindle speed||2900 - 3000 RPM|
|Saw spindle diameter||70 mm|
|Feed speed||5-10 M/min|
|Number of feed rollers||10|
|Number of table rollers||8|
|Table surface area (width)||320 mm|
|Table surface area (length)||3235 mm|
|Saw spindle motor (upper)||30-50HP|
|Saw spindle motor (lower)||50-75HP (Option)|
|Feed drive motor||7.5HP|
|Upper saw spindle elevation motor||1 HP x 1|
|Lower saw spindle elevation motor||1 HP x 1|
|Upper feed roller elevation motor||1 HP x 1|
|Net weight||2900 KGS|
|Gross weight||3300 KGS|
|Machine size||4225 x 1349 x 1930 mm|
|Packing dimensions||4445 x 1549 x 2184 mm|
